Product Line
Iron & Steel Industry
RH Degasser
| Grade and Zone | Mgo % |
Sio2 % |
Cao % |
Fe2O3 % |
Al2O3 % |
Cr2O3 % |
TiO2 % |
K20 + Na2O % |
BD g/cc |
AP Vol % |
CCS N/mm2 |
Grain Size MM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Working Lining | ||||||||||||
| Hot Take Off | ||||||||||||
| iFIRED-MCR-DB-M68 | 68.2 | 1.8 | 1.5 | 8.1 | 3.6 | 16.8 | - | - | 3.1 | 16.9 | 50.2 | |
| Upper Vessel | ||||||||||||
| iFIRED-MCR-SF-M62 | 63.8 | 1.5 | 1.2 | 8.6 | 6.5 | 18.4 | - | - | 3.2 | 14.6 | 51.5 | |
| iFIRED-MCR-DB-M65 | 65.0 | 1.7 | 1.5 | 8.2 | 6.3 | 17.0 | - | - | 3.15 | 16 | 45 | |
| Lower Vessel/Alloy Chute | ||||||||||||
| Snorkel | ||||||||||||
| iFIRED-MCR-F-M58 | 58.3 | 1.5 | 1.6 | 9.5 | 4.8 | 24.3 | - | - | 3.28 | 13.5 | 65 | |
| iFIRED-MCR-SF-M58 | 57.1 | 1.5 | 1.5 | 8.8 | 6.8 | 24.3 | - | - | 3.25 | 15 | 60 | |
| Safety Lining Options | ||||||||||||
| iFIRED-CH-40D | 0.3 | 54.6 | 0.2 | 1.3 | 41.4 | - | 1.6 | 1.0 | 2.2 | 16.0 | 40 | |
| iFIRED-BCH-70 | 22.5 | 1.2 | 71.8 | - | 3.5 | 1.0 | 2.5 | 21.5 | 70 | |||
| iFIRED-IFB-24-HS | 0.7 | 59.4 | 0.2 | 1.7 | 36.5 | - | - | 1.5 | 1.1 | 60 | 5 | |
| iFIRED-IFB-26-HS | 0.7 | 59.4 | 0.2 | 1.7 | 36.5 | - | - | 1.5 | 1.2 | 58 | 6 | |
| Monolithic | ||||||||||||
| iCAST-A96-CA | 0.2 | 3.0 | 0.1 | 96.0 | - | - | - | 2.97 | - | 100 | 0-5 | |
| iRAM-MCR-M54 | 57.2 | 1.8 | 1.2 | 11.7 | 7.6 | 20.5 | - | - | 2.75 | - | 42 | 0-5 |
